2.4 kW | 3.3 HP
3,800 in²
26 gal
Three bypass motors create the vacuum, and each motor can be controlled separately using an individual switch, allowing the operator to adjust the suction power. The motors are enclosed in a robust housing that contains a sound-absorbing sponge to ensure a quiet operation.
An M class polyester filter ensures effective filtration. Its unique star-shaped design allows air to pass through even when the filter is dirty. The filter fabric is classified as M Class according to BIA | EN 60335-2-69 standards. This classification means that the filter can capture particles up to 1 micron in size, providing protection for both the motors and the operator using the vacuum cleaner.
The TAN inlet + cyclone creates a cyclonic airflow that slows incoming material and helps heavier particles, chips, shavings, and debris drop into the collection bin before reaching the primary filter. This helps improve material separation and reduce direct filter loading during demanding industrial cleanup applications.
The debris is accumulated within a painted container that is equipped with a metal handle, allowing for easy detachment from the machine. The container is supported by four swiveling wheels, enabling effortless mobility and emptying. Each wheel is reinforced to ensure optimal stability when handling the bin.
